SR5900 ifm ⍾ SRM12XXBFPKG/

Control monitor for flow sensors; Operating voltage [V] : 19...36 DC; Protection class : III; Reverse polarity protection : yes; Power-on delay time [s] : 10; Number of channels : 1; Electrical design : PNP; Max. voltage drop switching output DC [V] : 2.5; Permanent current rating of switching output DC [mA] : 250; Switching function flow monitoring : output switches when flow is present: ON for output function = normally open / OFF for output function = normally closed; Short-circuit protection : yes; Overload protection : yes; Adjustment of the switch point : pushbutton; Ambient temperature [°C] : -20...60; Materials : stainless steel (1.4404 / 316L); stainless steel (1.4301 / 304); PC; PBT-GF20; EPDM/X; brass

Type

Flow sensors / flow meters

Connection

Connector: 1 x M12

No. of inputs/outputs

Number of analogue outputs: 2

Current consumption

< 70 mA

Voltage supply

24 V

Display

function: LED, bar graph | switching status: LED, orange flash in case of wire break

Degree of protection

IP 67; (with sensor attached)

Weight

225.5 g

Dimensions

104.5 x 32.5 x 113.6 mm
