SN2303 ifm ⍾ VS2000/200VAC/EXI/1G

Control monitor for flow sensors; Frequency AC [Hz] : 47...63; Operating voltage tolerance [%] : -10...10; Operating voltage [V] : < 200 AC; Max. power consumption [VA] : 5; Reverse polarity protection : no; Power-on delay time [s] : 30; Number of channels : 1; Electrical design : relay; Contact rating : 4 A (250 V AC cos phi > 0,7) ; 0,2 A (250 V DC); 4 A (24 V DC); Switching function flow monitoring : relay energised when flow is present; Switching function wire break monitoring : relay de-energised in case of wire break; Short-circuit proof : no; Overload protection : no; Adjustment of the switch point : potentiometer; Selection liquids / gases : slide switch; Ambient temperature [°C] : -20...60; Storage temperature [°C] : -20...85; Protection rating terminals : IP 20; Housing : housing for DIN rail mounting; Materials : plastics

Type

Flow sensors / flow meters

Connection

terminals: 15 x ...2.5 mm²

No. of inputs/outputs

Number of analogue outputs: 2

Current consumption

< 150 mA

Voltage supply

24 V

Display

function: 11 x LED | switching status: LED, red

Degree of protection

IP 40

Weight

548.5 g

Dimensions

78 x 45 x 120 mm
