OS0033 ifm ⍾ OSP-FBOA

Retro-reflective sensor; Operating voltage [V] : 20...250 AC/DC; Protection class : II; Reverse polarity protection : no; Type of light : red light; Wave length [nm] : 660; Output function : light-on/dark-on mode; (programmable); Max. voltage drop switching output DC [V] : 10.5; Max. voltage drop switching output AC [V] : 10.5; Minimum load current [mA] : 15; Max. leakage current [mA] : 6; Permanent current rating of switching output AC [mA] : 250; (350 (...50 °C)); Permanent current rating of switching output DC [mA] : 250; (350 (...50 °C)); Short-time current rating of switching output [mA] : 2200; (10 ms / 0,5 Hz); Switching frequency AC [Hz] : 25; Switching frequency DC [Hz] : 25; Short-circuit proof : no; Overload protection : no; Range referred to prismatic reflector [m] : 6; (Prismatic reflector Ø 80 E20005); Range adjustable : yes; Polarisation filter available : yes; Ambient temperature [°C] : -25...60; Housing : rectangular; Materials : PPO modified; Lens material : glass; Lens alignment : side lens; Items supplied : Angle bracket: 1, E20210 | screwdrivers

Type

Photoelectric sensors

Connection

terminals: ...1.5 mm²; Cable gland: M20 X 1.5

No. of inputs/outputs

Number of digital outputs: 2

Current consumption

18 mA

Voltage supply

24 V

Display

switching status: 1 x LED, yellow

Degree of protection

IP 65

Weight

277.5 g

Dimensions

80 x 28 x 95 mm
