OF5019 ifm ⍾ OFE-FPKG

Through-beam sensor receiver; Operating voltage [V] : 10...36 DC; Protection class : II; Reverse polarity protection : yes; Type of light : infrared light; Wave length [nm] : 880; Electrical design : PNP; Output function : light-on/dark-on mode; (programmable); Max. voltage drop switching output DC [V] : 2.5; Permanent current rating of switching output DC [mA] : 200; Switching frequency DC [Hz] : 320; Short-circuit protection : yes; Type of short-circuit protection : pulsed; Overload protection : yes; Transmitter / receiver : receiver; Range [m] : < 4; Ambient temperature [°C] : -25...60; Housing : threaded type; Thread designation : M12 x 1; Materials : brass nickel-plated; Lens material : PMMA; Items supplied : lock nuts: 2 x

Type

Photoelectric sensors

Connection

Cable: 2 m, PUR; 3 x 0.34 mm²

No. of inputs/outputs

Number of digital outputs: 2

Current consumption

< 25 mA

Voltage supply

24 V

Display

switching status: 1 x LED, yellow | operation: 1 x LED, green

Degree of protection

IP 67

Weight

73 g

Dimensions

M12 x 1 / L = 60 mm
