M18SP6FF25 BANNER ⍾ 58429

M18 Series 18mm Metal Barrel-Mount Sensor; EZ-BEAM M18 Series: Fixed Field Range: 25 mm; Input: 10-30V dc Complementary PNP2 m (6.5 ft) Cable; Cable Length (m) : 2; Sensing Mode (General) : Proximity; Sensing Mode (Detailed) : Background Suppression (Fixed); Housing Style : Barrel; Primary Housing Material : Stainless Steel; Input/Output : Discrete; Max Sensing Distance (mm) : 25; Outputs : PNP; Quick Disconnect Type : No QD; Operation : Light/Dark Operate; Min Op. Temp. (°C) : -40; Max Op. Temp. (°C) : 70; Output response time (ms) : 3; Repeatability (µs) : 750; Number of Pins : 4; NEMA Rating : NEMA 6P; Max Op. Relative Humidity [%] : 90% @ 50°C; Barrel Diameter (mm) : 18; Feature: Washdown Rated : Yes; Feature: Encapsulated : Yes; Feature: Chemical Resistant : Yes; Feature: Health/ Marginal Signal Output : Yes

Type

M18

Lens material

Acrylic

Sensing beam

Infrared LED

Connection

Cable

Typical response time

100 ms

Power supply type

DC

Power supply

10-30 V dc

Indicator

LEDs

Degree of protection

IP69
