7UT6135-5EB91-1BC0 L0A SIEMENS ⍾ 7UT61355EB911BC0L0A

DIGITAL DIFFERENTIAL PROTECTION RELAY, FOR TRANSFORMER, GENERATORS, MOTOR, SMALL BUSBARS AND SHORT CABLE, 4-LINE ALPHANUM.BACKLIT DISPLAY 14 PROGRAMMABLE LED, NAVIGATION KEYS, FUNCTION KEYS, NUMBER BLOCK, CASE 1/2 X 19", 5BI, 8BO, 1 WATCHDOG CONTACT, 11I, IEE, CURRENT TRANSFORMER: 5A SUPPLY VOLTAGE:DC 110V TO 250V, AC 115V/230V, TRIGGER LEVEL BINARY INPUT 88V FLUSH MOUNTING CASE, SCREW TERMINALS (DIRECT WIRING/RING LUGS) REGION WORLD, IEC/ANSI, LANGUAGE ENGLISH (LANGUAGE CHANGEABLE) SYSTEM PORT (ON REAR OF DEVICE) PORT B PROFIBUS DP SLAVE, RS485 DIGSI 4/MODEM PORT (ON REAR OF DEVICE) PORT C DIGSI4, BROWSER,ELECTRIC. RS232 BASIS MEASURED VALUES, FAULT RECORDING RESTRICTED EARTH FAULT LOW IMPEDANCE (87N) UMZ - 1-PHASE FOR RESTRICTED EARTH FAULT HIGH IMPEDANCE (87N W/O RESISTOR AND VARISTOR) SENSITIVE OVERCURR.-TIME PROT./ TANK PROTECTION (64) NEGATIVE SEQUENCE PROTECT. (46) BREAKER FAILURE PROTECT. (50BF) TRIP CIRCUIT SUPERVISION (74TC) ADDITIONAL FUNCTION: VOLTGAE MEASUREMENT AND OVEREXCITATION PROTECTION, OVER- /UNDERVOLTAGE PROTECTION, FREQUENCY PROTECTION, DIRECTIONAL PROTECTION, FUSE FAILURE MONITOR WITHOUT ADDITIONAL FUNCTIONS

Typ

7UT

Kod taryfy celnej

85363010

Kraj pochodzenia

DE

Waga

8.700 kg
