WTF9C-3P2462A00 SICK1099064WTF9C3P2462A00

Features: Sensor/ detection principle: Photoelectric proximity sensor, Foreground suppression; Dimensions (W x H x D): 12.2 mm x 52.2 mm x 23.6 mm; Housing design (light emission): Rectangular; Mounting hole: M3; Sensing range max.: 20 mm ... 350 mm 1); Sensing range: 20 mm ... 200 mm 2); Type of light: Visible red light; Light source: PinPoint LED 3); Light spot size (distance): Ø 4.5 mm (75 mm); Wave length: 650 nm; Adjustment: IO-LinkSingle teach-in button; Pin 2 configuration: External input, Teach-in input, Sender off input, Detection output, logic output; Mechanics/electronics: Supply voltage: 10 V DC ... 30 V DC 1); Ripple: < 5 Vpp 2); Power consumption: 30 mA 3); Switching output: PNP 4); Output function: Complementary; Switching mode: Light/dark switching 4); Output current Imax.: ≤ 100 mA 5); Response time: < 0.333 ms 6); Response time Q/ on Pin 2: 200 µs ... 300 µs 6) 7); Switching frequency: 1,500 Hz 8); Switching frequency Q / to pin 2: ≤ 1,500 Hz 9); Connection type: Male connector M12, 4-pin; Circuit protection: A 10)B 11)C 12); Protection class: III; Weight: 13 g; IO-Link: ✔; Housing material: Plastic, VISTAL®; Optics material: Plastic, PMMA; Enclosure rating: IP66IP67IP69K; Ambient operating temperature: –40 °C ... +60 °C; Ambient storage temperature: –40 °C ... +75 °C; UL File No.: NRKH.E181493; Repeatability Q/ on Pin 2:: 100 µs 7); Communication interface: Communication interface: IO-Link V1.1; Communication Interface detail: COM2 (38,4 kBaud); Cycle time: 2.3 ms; Process data length: 16 Bit; Process data structure: Bit 0 = switching signal QL1Bit 1 = switching signal QL2Bit 2 ... 15 = empty; VendorID: 26; DeviceID HEX: 0x800226; DeviceID DEC: 8389158; Smart Task: Smart Task name: Base logics; Logic function: DirectANDORWINDOWHysteresis; Timer function: DeactivatedOn delayOff delayON and OFF delayImpulse (one shot); Inverter: Yes; Switching frequency: SIO Direct: 1500 Hz 1)SIO Logic: 600 Hz 2)IOL: 450 Hz 3); Response time: SIO Direct: 200 µs ... 300 µs 1)SIO Logic: 650 µs ... 750 µs 2)IOL: 650 µs ... 1000 µs 3); Repeatability: SIO Direct: 100 µs 1)SIO Logic: 100 µs 2)IOL: 350 µs 3); Switching signal QL1: Output type (dependant on the adjusted threshold); Switching signal QL2: Output type (dependant on the adjusted threshold); Classifications: ECl@ss 5.0: 27270904; ECl@ss 5.1.4: 27270904; ECl@ss 6.0: 27270904; ECl@ss 6.2: 27270904; ECl@ss 7.0: 27270904; ECl@ss 8.0: 27270904; ECl@ss 8.1: 27270904; ECl@ss 9.0: 27270904; ECl@ss 10.0: 27270904; ECl@ss 11.0: 27270904; ETIM 5.0: EC002719; ETIM 6.0: EC002719; ETIM 7.0: EC002719; UNSPSC 16.0901: 39121528
