VNA001 ifm ⍾ VIBRATION SENSOR

Vibration sensor; Operating voltage [V] : 7.2...30 DC; Min. insulation resistance [MΩ] : 100; (500 V DC); Protection class : III; Reverse polarity protection : yes; Sensor type : microelectromechanical system (MEMS); Analogue current output [mA] : 0...10; Max. load [Ω] : 300; Measuring range of vibration [g] : -25...25; Frequency range [Hz] : 1...6000; Measuring principle : capacitive; Sensitivity [µA/g] : 142; Number of measurement axes : 1; Linearity deviation : 0,2 %; Ambient temperature [°C] : -30...125; Note on ambient temperature : cULus: < 85 °C; Storage temperature [°C] : -30...125; Type of mounting : M8 x 1,25; Materials : housing: stainless steel (1.4404 / 316L); Tightening torque [Nm] : 8; Mechanische Überlastfestigkeit [g] : 500; Items supplied : washer, conical; Connector: 1 x M12; Maximum cable length: 250 m

Type

Systems for vibration monitoring and diagnostics

Connection

Connector: 1 x M12

No. of inputs/outputs

Number of digital outputs: 1; Number of analogue outputs: 1

Current consumption

< 16 mA

Voltage supply

24 V

Display

operation: LED, green | switching status: LED, yellow

Degree of protection

IP 67; IP 68; IP 69K

Weight

49 g

Dimensions

M18 x 1 mm
