RAY10-KZ3EBLP06 SICK1098291RAY10KZ3EBLP06

Features: Sensor/ detection principle: Photoelectric retro-reflective sensor, Dual lensReflex Array; Dimensions (W x H x D): 21.5 mm x 36 mm x 37.7 mm; Housing design (light emission): Rectangular; Minimum object size: 5 mm, position-independent detection within the light array; Detection height: 25 mm; Sensing range max.: 0 m ... 1.5 m 1); Distance of the sensor to reflector: 0.3 m ... 1.5 m 1); Type of light: Visible red light; Light source: PinPoint LED 2); Light spot size (distance): 37 mm x 12 mm (1 m); Wave length: 635 nm; Adjustment: Potentiometer; AutoAdapt: ✔; Special applications: Detecting transparent objects, Detecting perforated objects, Detecting uneven, shiny objects, Detecting objects with position tolerances, Detecting flat objects; Mechanics/electronics: Supply voltage: 10 V DC ... 30 V DC 1); Ripple: ≤ 5 Vpp; Current consumption: 30 mA 2); Switching output: PNP 3); Switching mode: Dark switching; Signal voltage PNP HIGH/LOW: Approx. VS – 2.5 V / 0 V; Signal voltage NPN HIGH/LOW: Approx. VS / < 2.5 V; Output current Imax.: ≤ 100 mA; Response time: ≤ 0.5 ms 4); Switching frequency: 1,000 Hz 5); Connection type: Cable with M8 male connector, 4-pin, 1,000 mm 6); Cable material: PVC; Circuit protection: A 7)B 8)C 9)D 10); Protection class: III; Weight: 130 g; Housing material: Plastic, ABS; Optics material: Plastic, PMMA; Enclosure rating: IP67; Items supplied: RAY10 on bracket #4101235 with P250F on bracket #4101760; Ambient operating temperature: –40 °C ... +60 °C 11); Ambient storage temperature: –40 °C ... +70 °C; UL File No.: NRKH.E189383 & NRKH7.E189383; Classifications: ECl@ss 5.0: 27270902; ECl@ss 5.1.4: 27270902; ECl@ss 6.0: 27270902; ECl@ss 6.2: 27270902; ECl@ss 7.0: 27270902; ECl@ss 8.0: 27270902; ECl@ss 8.1: 27270902; ECl@ss 9.0: 27270902; ECl@ss 10.0: 27270902; ECl@ss 11.0: 27270902; ETIM 5.0: EC002717; ETIM 6.0: EC002717; ETIM 7.0: EC002717; UNSPSC 16.0901: 39121528
