O6E203 ifm ⍾ O6E-FPKG/AS/4P
Through-beam sensor receiver; Operating voltage [V] : 10...30 DC; Protection class : III; Reverse polarity protection : yes; Type of light : red light; Wave length [nm] : 633; Electrical design : PNP; Output function : light-on/dark-on mode; (selectable); Max. voltage drop switching output DC [V] : 2.5; Permanent current rating of switching output DC [mA] : 100; Switching frequency DC [Hz] : 1000; Short-circuit protection : yes; Type of short-circuit protection : pulsed; Transmitter / receiver : receiver; Range [m] : < 10; Range adjustable : yes; Ambient temperature [°C] : -25...60; Housing : rectangular; Materials : housing: ABS; PPSU; Lens material : PMMA; Lens alignment : side lens; Sealing material : EPDM; Tightening torque [Nm] : 0.5
- Connection
- Connector: 1 x M8; Locking: brass, coated; Sealing: EPDM
- No. of inputs/outputs
- Number of digital outputs: 2
- Current consumption
- 7; ((24 V)) mA
- Voltage supply
- 24 V
- Display
- switching status: 1 x LED, yellow | operation: 1 x LED, green
- Degree of protection
- IP 65; IP 67
- Weight
- 18.2 g
- Dimensions
- 46 x 13 x 21 mm
