N0033A ifm ⍾ NV1221/230VAC/RL/1D/1G

Switching amplifiers for Namur sensors; Operating voltage tolerance [%] : -10...10; Operating voltage [V] : < 230 AC; Max. power consumption [VA] : 1.3; Number of channels : 2; Electrical design : relay; (per channel: 1 changeover contact); Contact rating : 253 V AC / 2 A / cos phi > 0,7 // 40 V DC / 2 A; (ohmic resistance); Switching frequency AC [Hz] : 10; Ambient temperature [°C] : -20...60; Switching cycles mechanical : 10 million

Type

Inductive sensors

Connection

terminals: ...2.5 mm²

No. of inputs/outputs

Number of digital outputs: 2

Current consumption

< 40 mA

Voltage supply

24 V

Display

switching status: 2 x LED, yellow | operation: LED, green | function: 2 x LED, red

Degree of protection

IP 20

Weight

212 g

Dimensions

Ø 15 / L = 64.5 mm
