LL3-DL01 SICK ⍾ 1068060 ⍾ LL3DL01

Features: Device type: Fibers; Detection principle: Proximity system; For fiber-optic sensor: GLL170(T), WLL180T; Outer diameter, fiber-optic cable connection: 2.2 mm; Fiber-optic head design: Flat type; Fiber arrangement: Multi-fiber – fiber bundle; Core structure: Multi-fiber – fiber bundle; Angle of dispersion < 60°: No; Highly flexible/elastic fibers (bend radius 1–4 mm): No; Adapter end sleeves required: No; Angle of dispersion: 60°; Integrated lens: No; Compatibility tip adapters: No; Classifications: ECl@ss 5.0: 27270905; ECl@ss 5.1.4: 27270905; ECl@ss 6.0: 27270905; ECl@ss 6.2: 27270905; ECl@ss 7.0: 27270905; ECl@ss 8.0: 27270905; ECl@ss 8.1: 27270905; ECl@ss 9.0: 27270905; ECl@ss 10.0: 27270905; ECl@ss 11.0: 27270905; ETIM 5.0: EC002651; ETIM 6.0: EC002651; ETIM 7.0: EC002651; UNSPSC 16.0901: 39121528; Sensing ranges with GLL170: Operating mode 250 µs: 94 mm; Sensing ranges with GLL170T: Operating mode 50 µs: 77 mm; Operating mode 250 µs: 162 mm

Type

Fibers
