II5913 ifm ⍾ IIK3015A1PKG/US
Inductive analogue sensor; Operating voltage [V] : 15...30 DC; Protection class : II; Reverse polarity protection : yes; Analogue current output [mA] : 4...20; (linear; gradient: 1,143 mA/mm; for frontal approach and for target made of mild steel: 45 x 45 x 1 mm); Max. load [Ω] : 500; Short-circuit protection : yes; Overload protection : yes; Measuring range [mm] : 1...15; Correction factor : steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3; Linearity error of analogue output [%] : ± 1 %; (of IA max); Repeatability analogue output [%] : ± 1 %; (of IA max); Response time [ms] : < 20; Ambient temperature [°C] : -25...80; Housing : threaded type; Mounting : non-flush mountable; Thread designation : M30 x 1.5; Materials : housing: brass white bronze coated; sensing face: PBT; Tightening torque [Nm] : 50; Items supplied : lock nuts: 2
- Connection
- Connector: 1 x M12
- No. of inputs/outputs
- Number of analogue outputs: 1
- Current consumption
- < 20 mA
- Voltage supply
- 24 V
- Display
- within the operating range: 1 x LED, yellow lights | outside the operating range: 1 x LED, yellow flashing
- Degree of protection
- IP 67
- Weight
- 128.7 g
- Dimensions
- M30 x 1.5 / L = 70 mm
