IGC235 ifm ⍾ IGK2012-ASI /M/US-104

Inductive AS-Interface sensor; Operating voltage [V] : 26.5...31.6 DC; Protection class : III; Reverse polarity protection : yes; Max. power-on delay time [ms] : 1000; Electrical design : AS-i; Switching frequency DC [Hz] : 100; Sensing range [mm] : 12; Real sensing range Sr [mm] : 12 ± 10 %; Operating distance [mm] : 0...9.7; Correction factor : steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.45 / copper: 0.35; Hysteresis [% of Sr] : 1...20; Switch point drift [% of Sr] : -10...10; Ambient temperature [°C] : -25...70; Housing : threaded type; Mounting : non-flush mountable; Thread designation : M18 x 1; Materials : threaded sleeve: stainless steel (1.4404 / 316L); sensing face: LCP uncoloured; lock nuts: brass; Items supplied : lock nuts: 2

Type

Inductive sensors

Connection

Connector: 1 x M12; Contacts: gold-plated

No. of inputs/outputs

Number of analogue outputs: 1

Current consumption

< 30 mA

Voltage supply

24 V

Display

switching status: 4 x 90° LED, yellow | function: 1 x LED, red

Degree of protection

IP 68; ("Coolant")

Weight

46.4 g

Dimensions

M18 x 1 / L = 60 mm
