IF6029 ifm ⍾ IFK3002A2PKG/US

Inductive analogue sensor; Operating voltage [V] : 15...30 DC; Protection class : II; Reverse polarity protection : yes; Electrical design : PNP/NPN; (parameterisable); Output function : normally open / normally closed; (parameterisable); Max. voltage drop switching output DC [V] : 2.5; Permanent current rating of switching output DC [mA] : 100; Switching frequency DC [Hz] : 200; Analogue voltage output [V] : 0...10; (linear; gradient: 5,556 V/mm; for frontal approach and for target made of mild steel: 12 x 12 x 1 mm); Min. load resistance [Ω] : 2000; Short-circuit protection : yes; Overload protection : yes; Measuring range [mm] : 0.2...2; Switch point IO-Link [mm] : 0.38...1.87; Correction factor : steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.3 / copper: 0.2; Hysteresis [% of Sr] : 3...15; Note on hysteresis : parameterisable; Linearity error of analogue output [%] : ± 1; (of the final value of the measuring range); Repeatability analogue output [%] : ± 1; (of the final value of the measuring range); Temperature coefficient [%/K vom MEW] : ±0,15; Temperature drift [% vom MEW] : ±5; Response time [ms] : < 10; Communication interface : IO-Link; Transmission type : COM2 (38,4 kBaud); IO-Link revision : 1.1; SDCI standard : IEC 61131-9; Profiles : Smart Sensor: Identification and diagnosis; Multi-channel, two setpoint switching sensor, type 0 Generic Profiled Sensor; Teach Channel; SIO mode : yes; Required master port type : A; Min. process cycle time [ms] : 3.2; IO-Link process data (cyclical) : function: bit length | process value: 16 | device status: 4 | binary switching information: 2; IO-Link functions (acyclical) : switching cycles counter; switch-on cycle counter; operating hours counter; internal temperature; application specific tag; Supported DeviceIDs : Type of operation: DeviceID | Default: 1206; Note : For further information please see the IODD PDF file under "Downloads"; Ambient temperature [°C] : -25...80; Housing : threaded type; Mounting : flush mountable; Thread designation : M12 x 1; Materials : Housing: brass white bronze coated; sensing face: PBT orange; LED-Fenster: PEI; lock nuts: brass white bronze coated; Tightening torque [Nm] : 7; Items supplied : lock nuts: 2

Connection

Connector: 1 x M12

No. of inputs/outputs

Number of analogue outputs: 1

Current consumption

< 30 mA

Voltage supply

24 V

Display

target in measuring range: 4 x LED, yellow lights | target outside measuring range: 4 x LED, yellow flashing

Degree of protection

IP 65; IP 66; IP 67; IP 68; IP 69K

Weight

32.4 g

Dimensions

M12 x 1 / L = 70 mm
