IB5163 ifm ⍾ IB-3027SFPKG RT

Inductive sensor; Operating voltage [V] : 10...36 DC; Protection class : II; Reverse polarity protection : yes; Electrical design : PNP; Output function : normally open / normally closed; (selectable); Max. voltage drop switching output DC [V] : 3; Permanent current rating of switching output DC [mA] : 250; Short-time current rating of switching output [mA] : 400; Switching frequency DC [Hz] : 20; Short-circuit protection : yes; Type of short-circuit protection : pulsed; Overload protection : yes; Sensing range [mm] : 27; Real sensing range Sr [mm] : 27 ± 10 %; Operating distance [mm] : 0...21.87; Correction factor : steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3; Hysteresis [% of Sr] : 1...15; Switch point drift [% of Sr] : -10...10; Ambient temperature [°C] : -30...50; Housing : cylindrical; Mounting : non-flush mountable; Materials : PBT; Items supplied : Mounting clamps: 1

Type

Inductive sensors

Connection

Cable: 2 m, PVC; 4 x 0.34 mm²

No. of inputs/outputs

Number of analogue outputs: 1

Current consumption

15; (24 V) mA

Voltage supply

24 V

Display

switching status: 1 x LED, red

Degree of protection

IP 67

Weight

257.5 g

Dimensions

Ø 34 / L = 82 mm
