ifm IB0016

IB0016 ifm ⍾ IBE2020-FBOA

Inductive sensor; Operating voltage [V] : 20...250 AC/DC; Protection class : II; Reverse polarity protection : no; Output function : normally open / normally closed; (selectable); Max. voltage drop switching output DC [V] : 6; Max. voltage drop switching output AC [V] : 6.5; Minimum load current [mA] : 5; Max. leakage current [mA] : 2.5 (250 V AC) / 1.3 (110 V AC) / 0.8 (24 V DC); Permanent current rating of switching output AC [mA] : 250; (350 (...50 °C)); Permanent current rating of switching output DC [mA] : 100; Short-time current rating of switching output [mA] : 2200; (20 ms / 0,5 Hz); Switching frequency AC [Hz] : 25; Switching frequency DC [Hz] : 50; Short-circuit proof : no; Overload protection : no; Sensing range [mm] : 20; Real sensing range Sr [mm] : 20 ± 10 %; Operating distance [mm] : 0...16.2; Correction factor : steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.4 / copper: 0.3; Hysteresis [% of Sr] : 3...15; Switch point drift [% of Sr] : -10...10; Ambient temperature [°C] : -25...80; Housing : cylindrical; Mounting : non-flush mountable; Materials : PBT; end cap: PC; Items supplied : Mounting clamps: 1

Connection
terminals: ...2.5 mm²; Cable sheath: Ø 7...13 mm; Cable gland: M20 X 1.5
No. of inputs/outputs
Number of analogue outputs: 1
Current consumption
15; (24 V) mA
Voltage supply
24 V
Display
switching status: 1 x LED, yellow
Degree of protection
IP 65
Weight
184.5 g
Dimensions
Ø 34 / L = 98 mm
