I7R205 ifm ⍾ I7R3015-FPKG/US-100-IPF
Inductive ring sensor; Operating voltage [V] : 10...35 DC; Protection class : III; Reverse polarity protection : yes; Electrical design : PNP; Output function : normally open / normally closed; (selectable); Max. voltage drop switching output DC [V] : 2; Permanent current rating of switching output DC [mA] : 200; Short-circuit protection : yes; Overload protection : yes; Resolution of steel ball (diameter) [mm] : 2; Max. part speed [m/s] : 35; Pulse stretching [ms] : 10...150; Pulse stretching adjustable : yes; Max. fall time [ms] : 10; Response time [ms] : < 0.5; Ambient temperature [°C] : -25...70; Housing : circular; Inside diameter [mm] : 15.1; Materials : housing: PA; ring: POM
- Connection
- Connector: 1 x M12
- No. of inputs/outputs
- Number of analogue outputs: 1
- Current consumption
- < 11 mA
- Voltage supply
- 24 V
- Display
- switching status: 1 x LED, yellow
- Degree of protection
- IP 67
- Weight
- 60.5 g
- Dimensions
- 60 x 35 x 20 mm
