E11144 ifm ⍾ SSTGH040ZDSFKSK

Wirable plug; Max. current load total [A] : 4; Ambient temperature [°C] : -25...60; Materials : PA 6.6; Moulded-body material : PA 6.6; Material nut : zinc, nickel-plated; insulation displacement technology: 0.34...0.75 mm²; Core insulation: PVC / PE; (Ø ...2.5 mm); Cable sheath: Ø 4...7.5 mm

Type

Wirable plugs

Connection

Connector: 1 x M12, straight; Moulded body: PA 6.6; Locking: zinc, nickel-plated

No. of inputs/outputs

Number of analogue inputs: 2; Number of digital outputs: 4; Number of analogue outputs: 1

Current consumption

100 mA

Voltage supply

20...30; (via flat cable) V

Display

operation: 1 x LED, yellow

Degree of protection

IP 67

Weight

15.4 g

Dimensions

18 x 18 x 55 mm
