DI602A ifm ⍾ DGA4012-WPKG/US/3D
Compact evaluation unit for speed monitoring; Nominal voltage DC [V] : 10...36; Protection class : II; Reverse polarity protection : yes; Electrical design : PNP; Output function : normally open / normally closed; (parameterisable); Max. voltage drop switching output DC [V] : 2.5; Permanent current rating of switching output DC [mA] : 150; (when used outside the hazardous area: 250; Pulse output: 15); Short-circuit protection : yes; Type of short-circuit protection : pulsed; Overload protection : yes; Sensing range [mm] : 8; Sensing range adjustable : no; Operating distance [mm] : 0...6; Setting range [Imp/min] : 3...6000; Correction factor : steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3; Hysteresis [% of Sr] : 10; Start-up delay [s] : 0...15; Max. damping frequency [Imp/min] : 18000; Adjustment of the switch point : Teach function; Ambient temperature [°C] : -20...50; Note on ambient temperature : when used outside the hazardous area: -20...60 °C; Storage temperature [°C] : -25...60; Mounting : non-flush mountable; Thread designation : M18 x 1; Materials : stainless steel (1.4571/316Ti ); PBT; TPE-U; Items supplied : lock nuts: 2 | Impact protection housing | Mounting clamps
- Connection
- Connector: 1 x M12; Contacts: gold-plated
- No. of inputs/outputs
- Number of analogue outputs: 1; Number of relay outputs: 2
- Current consumption
- < 15 mA
- Voltage supply
- 20...30; (via flat cable) V
- Display
- switching status: 1 x LED, yellow | operation: 1 x LED, green | input signal: 1 x LED, green
- Degree of protection
- IP 67
- Weight
- 177 g
- Dimensions
- M18 x 1 / L = 68 mm
