VS3AP5XLPQ BANNER ⍾ 62624

VS3 Series Miniature Sensor With Advanced Optics; VS3 Series: Polarized Retro Range: 250 mm; Input: 10 to 30 V dc Output: PNP Light Operate Pico M8 3-pin QD; Sensing Mode (General) : Retroreflective; Sensing Mode (Detailed) : Polarized (Coaxial); Housing Style : Rectangular; Primary Housing Material : Thermoplastic; Input/Output : Discrete; Max Sensing Distance (mm) : 250; Outputs : PNP; Quick Disconnect Type : M8 (Pico); Operation : Light Operate; Min Op. Temp. (°C) : -20; Max Op. Temp. (°C) : 55; Output response time (ms) : 1; Repeatability (µs) : 160; Number of Pins : 3; NEMA Rating : NEMA 6; Max Op. Relative Humidity [%] : 80% @ 50°C; Feature: Quick Disconnect : Yes

Type

VS3

Lens material

Glass

Sensing beam

Visible Red LED

Connection

Pigtail QD

Typical response time

150 ms

Power supply type

DC

Power supply

10-30 V dc

Indicator

LEDs

Degree of protection

IP67
