SMU31RL BANNER55897

Mini-Beam Series Industry Standard Sensor; MINI-BEAM UNIVERSAL: Receiver Range: 30 m; Input: 24-240V ac or 24-240V dc Output: SPDT Electromechanical Relay 2 m (6.5 ft) Cable; Cable Length (m) : 2; Sensing Mode (General) : Opposed; Sensing Mode (Detailed) : Receiver; Housing Style : Rectangular w/M18 Mount; Primary Housing Material : Thermoplastic; Input/Output : E/M Relay; Max Sensing Distance (mm) : 30000; Outputs : SPDT e/m Relay; Quick Disconnect Type : No QD; Operation : Light/Dark Operate; Min Op. Temp. (°C) : -20; Max Op. Temp. (°C) : 55; Output response time (ms) : 20; Number of Pins : 5; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, 13; Max Op. Relative Humidity [%] : 90% @ 50°C; Adjustments : Potentiometer; Barrel Diameter (mm) : 18; Opposed Mode Emitter/Receiver : Receiver; Feature: Encapsulated : Yes

Lens material
Acrylic
Sensing beam
Infrared LED
Connection
Cable
Power supply type
AC/DC Universal
Power supply
24-240 V ac/dc
Indicator
LEDs
Degree of protection
IP67
