SMU315D BANNER ⍾ 52570

Mini-Beam Series Industry Standard Sensor; MINI-BEAM UNIVERSAL: Diffuse Range: 380 mm; Input: 24 to 240V ac or dc Output: SPDT Electromechanical Relay 2 m (6.5 ft) cable; Cable Length (m) : 2; Sensing Mode (General) : Proximity; Sensing Mode (Detailed) : Diffuse; Housing Style : Rectangular w/M18 Mount; Primary Housing Material : Thermoplastic; Input/Output : E/M Relay; Max Sensing Distance (mm) : 380; Outputs : SPDT e/m Relay; Quick Disconnect Type : No QD; Operation : Light/Dark Operate; Min Op. Temp. (°C) : -20; Max Op. Temp. (°C) : 55; Output response time (ms) : 20; Number of Pins : 5; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, 13; Max Op. Relative Humidity [%] : 90% @ 50°C; Adjustments : Potentiometer; Barrel Diameter (mm) : 18; Feature: Encapsulated : Yes

Type

MINI-BEAM

Lens material

Acrylic

Sensing beam

Infrared LED

Connection

Cable

Power supply type

AC/DC Universal

Power supply

24-240 V ac/dc

Indicator

LEDs

Degree of protection

IP67
