BANNER SMA31ELQDP

SMA31ELQDP BANNER ⍾ 29554

Mini-Beam Series Industry Standard Sensor; MINI-BEAM: Emitter Range: 30 m; Input: 24-240V ac Not applicable - no outupt 6 in Pigtail QD Connector; Sensing Mode (General) : Opposed; Sensing Mode (Detailed) : Emitter; Housing Style : Rectangular w/M18 Mount; Primary Housing Material : Thermoplastic; Max Sensing Distance (mm) : 30000; Quick Disconnect Type : 1/2 in. (Micro); Min Op. Temp. (°C) : -20; Max Op. Temp. (°C) : 70; Output response time (ms) : 2 ON/1 OFF; Repeatability (µs) : 300; Number of Pins : 3; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, 13; Max Op. Relative Humidity [%] : 90% @ 50°C; Adjustments : Potentiometer; Barrel Diameter (mm) : 18; Opposed Mode Emitter/Receiver : Emitter; Feature: Encapsulated : Yes; Feature: Quick Disconnect : Yes

Lens material
Acrylic
Sensing beam
Infrared LED
Connection
Pigtail QD
Typical response time
300 ms
Power supply type
AC
Power supply
24-240 V ac
Indicator
LEDs
Degree of protection
IP67
