SM31RL W/18 BANNER

This product has been marked as discontinued. Please ask for availability or replacement.

Mini-Beam Series Industry Standard Sensor; MINI-BEAM: Receiver Range: 30 m; Input: 10-30 V dc Output: Bipolar: 1 NPN; 1 PNP 5.5 m (18 ft) cable; Sensing Mode (General) : Opposed; Housing Style : Rectangular w/M18 Mount; Primary Housing Material : Thermoplastic; Input/Output : Discrete; Max Sensing Distance (mm) : 30000; Outputs : Bipolar (NPN & PNP); Quick Disconnect Type : No QD; Operation : Light/Dark Operate; Min Op. Temp. (°C) : -20; Max Op. Temp. (°C) : 70; Repeatability (µs) : 140; Number of Pins : 4; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12; Max Op. Relative Humidity [%] : 90% @ 50°C; Adjustments : Potentiometer

Type

MINI-BEAM

Connection

Other

Lens material

Acrylic

Sensing beam

Infrared LED

Typical response time

100 ms

Power supply type

DC

Indicator

LEDs

Degree of protection

IP67
