SM31EL BANNER ⍾ 25724

Mini-Beam Series Industry Standard Sensor; MINI-BEAM: Emitter Range: 30 m; Input: 10-30V dc Output: Not applicable - No outputs 2 m (6.5 ft) cable; Cable Length (m) : 2; Sensing Mode (General) : Opposed; Sensing Mode (Detailed) : Emitter; Housing Style : Rectangular w/M18 Mount; Primary Housing Material : Thermoplastic; Max Sensing Distance (mm) : 30000; Quick Disconnect Type : No QD; Min Op. Temp. (°C) : -20; Max Op. Temp. (°C) : 70; Output response time (ms) : 1; Repeatability (µs) : 140; Number of Pins : 2; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12; Max Op. Relative Humidity [%] : 90% @ 50°C; Adjustments : Potentiometer; Barrel Diameter (mm) : 18; Opposed Mode Emitter/Receiver : Emitter; Feature: Encapsulated : Yes

Type

MINI-BEAM

Lens material

Acrylic

Sensing beam

Infrared LED

Connection

Cable

Typical response time

100 ms

Power supply type

DC

Power supply

10-30 V dc

Indicator

LEDs

Degree of protection

IP67
