SM31E W/30 BANNER ⍾ 3025718

Mini-Beam Series Industry Standard Sensor; MINI-BEAM: Emitter Range: 3 m; Input: 10-30 V dc Output: Not applicable - No outputs 9 m (30 ft) Cable; Sensing Mode (General) : Opposed; Housing Style : Rectangular w/M18 Mount; Primary Housing Material : Thermoplastic; Max Sensing Distance (mm) : 3000; Quick Disconnect Type : No QD; Min Op. Temp. (°C) : -20; Max Op. Temp. (°C) : 70; Repeatability (µs) : 140; Number of Pins : 2; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12; Max Op. Relative Humidity [%] : 90% @ 50°C; Adjustments : Potentiometer; Barrel Diameter (mm) : 18; Feature: Encapsulated : Yes

Type

MINI-BEAM

Alternative product id

25718

Lens material

Acrylic

Sensing beam

Infrared LED

Typical response time

100 ms

Power supply type

DC

Indicator

LEDs

Degree of protection

IP67
