SM312W W/30 BANNER ⍾ 3026417

Mini-Beam Series Industry Standard Sensor; MINI-BEAM: Divergent Diffuse Range: 130 mm; Input: 10-30 V dc Output: Bipolar: 1 NPN; 1 PNP 9 m (30 ft) Cable; Sensing Mode (General) : Proximity; Housing Style : Rectangular; Primary Housing Material : Thermoplastic; Input/Output : Discrete; Outputs : Bipolar (NPN & PNP); Quick Disconnect Type : No QD; Min Op. Temp. (°C) : -20; Operation : Light/Dark Operate; Max Op. Temp. (°C) : 70; Repeatability (µs) : 300; Number of Pins : 4; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12; Max Op. Relative Humidity [%] : 90% @ 50°C; Adjustments : Potentiometer; Feature: Encapsulated : Yes

Type

MINI-BEAM

Alternative product id

26417

Lens material

Acrylic

Sensing beam

Infrared LED

Typical response time

100 ms

Power supply type

DC

Indicator

LEDs

Degree of protection

IP67
