SM312FPBQD BANNER ⍾ 47279

MINI-BEAM Fiber Optic Amplifier; MINI-BEAM: Visible Blue 475 nm Plastic Fiber Optic Range: depends on fiber; Input: 10-30 V dc Output: Bipolar: 1 NPN; 1 PNPQuick-Disconnect Connector; Housing Style : Rectangular; Primary Housing Material : Thermoplastic; Input/Output : Discrete; Color LED - Amplifiers : Blue; Fiber Type : Plastic and Glass; Quick Disconnect Type : M12 (Euro); Output Type (Specific) : Single Discrete; Repeatability (µs) : 300; Number of Pins : 4; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12; Max Op. Temperature (°C) : 70; Min Op. Temperature (°C) : -20; Max Op. Relative Humidity (%) : 90% @ 50°C; Adjustments : Potentiometer; Indicator Display Type : Indicator LEDs; Minimum response time (ms) : 1; Feature: Quick Disconnect : Yes; Housing Material : Thermoplastic

Type

MINI-BEAM

Connection

Integral QD

Typical response time

100 ms

Power supply

10-30 V dc

Power supply type

DC

Degree of protection

IP67
