SM312CMHS W/30 BANNER35966

Mini-Beam Series Industry Standard Sensor; MINI-BEAM: Modified High Speed Infrared Convergent Focal Point: 16 mm; Input: 10-30V dc Output: Bipolar: 1 NPN; 1 PNPMHS Response Time =0.3 millisecond; 9m(30ft)Cable; Cable Length (m) : 9; Sensing Mode (General) : Proximity; Sensing Mode (Detailed) : Convergent; Housing Style : Rectangular w/M18 Mount; Primary Housing Material : Thermoplastic; Input/Output : Discrete; Max Sensing Distance (mm) : 16; Outputs : Bipolar (NPN & PNP); Quick Disconnect Type : No QD; Operation : Light/Dark Operate; Min Op. Temp. (°C) : -20; Max Op. Temp. (°C) : 70; Output response time (ms) : 0.3; Repeatability (µs) : 300; Number of Pins : 4; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12; Max Op. Relative Humidity [%] : 90% @ 50°C; Adjustments : Potentiometer; Barrel Diameter (mm) : 18; Feature: Encapsulated : Yes

Lens material
Acrylic
Sensing beam
Infrared LED
Connection
Cable
Typical response time
100 ms
Power supply type
DC
Power supply
10-30 V dc
Indicator
LEDs
Degree of protection
IP67
