SM2A312WQDP BANNER ⍾ 29559

Mini-Beam Series Industry Standard Sensor; MINI-BEAM: Divergent Diffuse Range: 130 mm; Input: 24-240V ac Output: SPDT Solid-state 2-wire 6 in Pigtail QD Connector; Sensing Mode (General) : Proximity; Sensing Mode (Detailed) : Divergent; Housing Style : Rectangular; Primary Housing Material : Thermoplastic; Input/Output : Solid-State AC Switch; Max Sensing Distance (mm) : 130; Outputs : Solid-State AC Switch; Quick Disconnect Type : 1/2 in. (Micro); Min Op. Temp. (°C) : -20; Operation : Light/Dark Operate; Max Op. Temp. (°C) : 70; Output response time (ms) : 8; Repeatability (µs) : 2600; Number of Pins : 3; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, 13; Max Op. Relative Humidity [%] : 90% @ 50°C; Adjustments : Potentiometer; Feature: Encapsulated : Yes; Feature: Quick Disconnect : Yes

Type

MINI-BEAM

Lens material

Acrylic

Sensing beam

Infrared LED

Connection

Pigtail QD

Typical response time

300 ms

Power supply type

AC

Power supply

24-240 V ac

Indicator

LEDs

Degree of protection

IP67
