SM2A312C2QDP BANNER ⍾ 35976

This product has been marked as discontinued. Please ask for availability or replacement.

Mini-Beam Series Industry Standard Sensor; MINI-BEAM: Infrared 880 nm Convergent Focal Point: 43 mm; Input: 24-240V ac Output: SPST Solid-state 2-wire 6 in Pigtail QD Connector; Sensing Mode (General) : Proximity; Sensing Mode (Detailed) : Convergent; Housing Style : Rectangular w/M18 Mount; Primary Housing Material : Thermoplastic; Input/Output : Solid-State AC Switch; Max Sensing Distance (mm) : 43; Outputs : Solid-State AC Switch; Quick Disconnect Type : 1/2 in. (Micro); Operation : Light/Dark Operate; Min Op. Temp. (°C) : -20; Max Op. Temp. (°C) : 70; Output response time (ms) : 4; Repeatability (µs) : 1300; Number of Pins : 3; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, 13; Max Op. Relative Humidity [%] : 90% @ 50°C; Adjustments : Potentiometer; Barrel Diameter (mm) : 18; Feature: Encapsulated : Yes; Feature: Quick Disconnect : Yes

Type

MINI-BEAM

Lens material

Acrylic

Sensing beam

Infrared LED

Connection

Pigtail QD

Typical response time

300 ms

Power supply type

AC

Power supply

24-240 V ac

Indicator

LEDs

Degree of protection

IP67
