SLE30B6VYQ BANNER ⍾ 55477

SLE10 & SLE30 Series Programmable Slot Sensors; SLE30 EXPERT Series: Teach Mode Slot Sensor Slot width: 30 mm; Input: 10-30V dc Output: Bipolar: 1 NPN; 1 PNPQuick-Disconnect Connector; Sensing Mode (Detailed) : Emitter/Receiver Pair; Housing Style : Slot; Primary Housing Material : Thermoplastic; Max Sensing Range (mm) : 30; Slot Depth/Array Length (mm) : 45; Minimum Object Detection (mm) : 1.8; Quick Disconnect Type : M12 (Euro); Outputs : Bipolar (NPN & PNP); Slot Overall Depth (mm) : 52; Slot Overall Depth (mm) : 72; Number of Pins : 5; Output response time (ms) : 0.15; Repeatability (µs) : 75; Adjustments : Teach Button; Special Feature: Remote Teach : Yes; Operation : Light/Dark Operate; Max Op. Temperature (°C) : 70; Min Op. Temperature (°C) : -20; Max Op. Relative Humidity (%) : 90% @ 50°C; NEMA Rating : NEMA 6; Feature: Quick Disconnect : Yes; Minimum Object Detection [mm] : 1.8

Connection: Integral QD
Lens material: Acrylic
Typical response time: 1000 ms
Power supply: 10-30 V dc
Indicator: LEDs
Degree of protection: IP67
