QS18VP6FF50Q7 BANNER ⍾ 71875
This product has been marked as discontinued. Please ask for availability or replacement.
QS18 Series All Purpose Photoelectric Sensor; WORLD-BEAM QS18 Series: Fixed-Field Range: 50 mm; Input: 10-30V dc Output: Complementay Solid State PNPIntegral Pico-Style Quick-Disconnect Connector; Sensing Mode (General) : Proximity; Sensing Mode (Detailed) : Background Suppression (Fixed); Housing Style : Rectangular w/M18 Mount; Primary Housing Material : ABS; Small Visible Spot : LED; Input/Output : Discrete; Max Sensing Distance (mm) : 50; Outputs : PNP; Quick Disconnect Type : M8 (Pico); Operation : Light/Dark Operate; Min Op. Temp. (°C) : -20; Max Op. Temp. (°C) : 70; Output response time (ms) : 0.85; Sensing Beam Wavelength : 630; Repeatability (µs) : 160; Number of Pins : 4; NEMA Rating : NEMA 6; Max Op. Relative Humidity [%] : 95% @ 50°C; Barrel Diameter (mm) : 18; Feature: Quick Disconnect : Yes
- Lens material
- Acrylic
- Sensing beam
- Visible Red LED
- Connection
- Integral QD
- Typical response time
- 100 ms
- Power supply type
- DC
- Power supply
- 10-30 V dc
- Indicator
- LEDs
- Degree of protection
- IP67
