MIAD9CVQ BANNER ⍾ 35234

Mini-Beam Series Industry Standard Sensor; MINI-BEAM NAMUR: Convergent Focal Point: 16 mm; Input: 5-15V dc Output: NAMUREuro M12 4-pin Integral QD; Sensing Mode (General) : Proximity; Sensing Mode (Detailed) : Convergent; Housing Style : Rectangular w/M18 Mount; Primary Housing Material : Thermoplastic; Input/Output : Discrete; Max Sensing Distance (mm) : 16; Outputs : Constant Current; Quick Disconnect Type : M12 (Euro); Operation : Light/Dark Operate; Min Op. Temp. (°C) : -40; Max Op. Temp. (°C) : 70; Output response time (ms) : 5; Special Feature: Intrinsically Safe : Yes; Number of Pins : 4; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, 13; Max Op. Relative Humidity [%] : 90% @ 50°C; Adjustments : Potentiometer; Barrel Diameter (mm) : 18; Feature: Encapsulated : Yes; Feature: Hazardous Area : Yes; Feature: Quick Disconnect : Yes

Type

MINI-BEAM

Lens material

Acrylic

Sensing beam

Visible Red LED

Connection

Integral QD

Power supply type

DC

Power supply

5-15 V dc

Indicator

LEDs

Degree of protection

IP67
