AC336A ifm ⍾ DUAL SENSOR T5 2SI 1DO T 3D

AS-Interface dual sensor for pneumatic quarter-turn actuators; Protection class : III; Electrical design : AS-i; Sensing range [mm] : 4; Operating distance target puck [mm] : 74; Ambient temperature [°C] : -10...50; Materials : housing: PBT orange; cover: PC black; Impact protection housing: stainless steel; Items supplied : Impact protection housing | Mounting plate: 1 | socket head screws: 2 x M5 x 35; Elektrischer Anschluss : Connector: 1 x M12; Moulded body: stainless steel

Type

Inductive dual sensors for quarter-turn actuators

Connection

Connector: 1 x M12; Moulded body: stainless steel

No. of inputs/outputs

Number of Pt100 inputs: 4

Current consumption

160 mA

Voltage supply

18...30; (DC AUX) V

Display

operation: 1 x LED, green | function: 1 x LED, yellow

Degree of protection

IP 5x; (when used outside the hazardous area: IP 67)

Weight

779.5 g

Dimensions

55 x 60 x 35 mm
