AC2453 ifm ⍾ CompactM12 4 SB V4A

AS-Interface CompactLine module; Max. current consumption from AS-i [mA] : 2000; Max. current load total [A] : 4; Additional voltage supply [V] : 20...30 DC; (AUX); Max. current consumption from additional supply [mA] : 2000; (AUX); Ambient temperature [°C] : -25...80; Storage temperature [°C] : -25...80; Max. relative air humidity [%] : 90; (non condensing); Max. height above sea level [m] : 2000; Type of mounting : AS-i flat cables directly connectable; Materials : PA 6.6; socket: stainless steel (1.4404 / 316L); threaded inserts in the lower part: stainless steel (1.4404 / 316L); O-ring: EPDM; piercing contacts: CuSn6 nickel-plated and tin-plated; screws stainless steel (1.4578 / 316Cu); Connector: M12; Accessories (optional) : Stainless steel sleeve, for installation in case of high mechanical stress , E70402

Type

Complete product line

Connection

Connector: 1 x M12; Moulded body: stainless steel

No. of inputs/outputs

Number of digital inputs: 4; Number of digital outputs: 4

Current consumption

< 160 mA

Voltage supply

20...30; (DC) V

Display

switching status: LED, yellow I1...I4, O1...O4 | operation: LED, green AS-i, AUX | errors: LED, red

Degree of protection

IP 67; (when flat cables are used E7400x / E7401x)

Weight

272 g

Dimensions

152 x 60 x 27 mm
