7UT6135-5EB99-1BA0 L0S+M1F SIEMENS ⍾ 7UT61355EB991BA0L0SM1F

DIGITAL DIFFERENTIAL PROTECTION RELAY, FOR TRANSFORMER, GENERATORS, MOTOR, SMALL BUSBARS AND SHORT CABLE, 4-LINE ALPHANUM.BACKLIT DISPLAY 14 PROGRAMMABLE LED, NAVIGATION KEYS, FUNCTION KEYS, NUMBER BLOCK, CASE 1/2 X 19", 5BI, 8BO, 1 WATCHDOG CONTACT, 11I, IEE, CURRENT TRANSFORMER: 5A SUPPLY VOLTAGE:DC 110V TO 250V, AC 115V/230V, TRIGGER LEVEL BINARY INPUT 88V FLUSH MOUNTING CASE, SCREW TERMINALS (DIRECT WIRING/RING LUGS) REGION WORLD, IEC/ANSI, LANGUAGE ENGLISH (LANGUAGE CHANGEABLE) SYSTEM PORT (ON REAR OF DEVICE) PORT B IEC 61850,100 MBIT ETHERNET WITH INTEGRATED SWITCH OPTICAL, DOUBLE, LC-CONNECTOR (FROM OCT. 09) SERVICE INTERFACE (PORT C) DIGSI 4/MODEM ELECTRICAL RS232 ADDITIONAL INTERFACE (PORT D) TEMPERATURE MONITORING DEVICE, ELECTRICAL RS485 BASIS MEASURED VALUES, FAULT RECORDING RESTRICTED EARTH FAULT LOW IMPEDANCE (87N) UMZ - 1-PHASE FOR RESTRICTED EARTH FAULT HIGH IMPEDANCE (87N W/O RESISTOR AND VARISTOR) SENSITIVE OVERCURR.-TIME PROT./ TANK PROTECTION (64) NEGATIVE SEQUENCE PROTECT. (46) BREAKER FAILURE PROTECT. (50BF) TRIP CIRCUIT SUPERVISION (74TC) WITHOUT ADDIT. VOLTAGE FUNCTION WITHOUT ADDITIONAL FUNCTIONS

Type

7UT

Customs tariff number

85363010

Expected origin

DE

Weight

8.700 kg
