IG5319 ifm ⍾ IGB3008-APKG/US-104

Inductive sensor; Operating voltage [V] : 10...30 DC; Protection class : II; Reverse polarity protection : yes; Electrical design : PNP; Output function : normally closed; Max. voltage drop switching output DC [V] : 2.5; Permanent current rating of switching output DC [mA] : 100; Switching frequency DC [Hz] : 300; Short-circuit protection : yes; Overload protection : yes; Sensing range [mm] : 8; Real sensing range Sr [mm] : 8 ± 10 %; Operating distance [mm] : 0...6.48; Correction factor : steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3; Hysteresis [% of Sr] : 3...15; Switch point drift [% of Sr] : -10...10; Ambient temperature [°C] : -25...70; Housing : threaded type; Mounting : non-flush mountable; Thread designation : M18 x 1; Materials : brass white bronze coated; sensing face: PBT orange; LED window: PEI; lock nuts: brass white bronze coated; Items supplied : lock nuts: 2

Tipo

Detectores inductivos

Conexión

Connector: 1 x M12; Contacts: gold-plated

Número de entradas/salidas

Number of analogue outputs: 1

Consumo actual

< 10 mA

Suministro de voltaje

24 V

Mostrar

switching status: 4 x LED, yellow

Grado de protección

IP 67

Peso

41.8 g

Dimensiones

M18 x 1 / L = 50 mm
