IF5580 ifm ⍾ IFA3002-BPKG/US-104

Inductive sensor; Operating voltage [V] : 10...30 DC; Protection class : III; Reverse polarity protection : yes; Electrical design : PNP; Output function : normally open; Max. voltage drop switching output DC [V] : 2.5; Permanent current rating of switching output DC [mA] : 200; Switching frequency DC [Hz] : 800; Short-circuit protection : yes; Overload protection : yes; Sensing range [mm] : 2; Real sensing range Sr [mm] : 2 ± 10 %; Operating distance [mm] : 0...1.62; Correction factor : steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3; Hysteresis [% of Sr] : 3...15; Switch point drift [% of Sr] : -10...10; Ambient temperature [°C] : -25...80; Housing : threaded type; Mounting : flush mountable; Thread designation : M12 x 1; Materials : brass white bronze coated; sensing face: PBT orange; LED window: PEI; lock nuts: brass white bronze coated; Items supplied : lock nuts: 2

Tipo

Detectores inductivos

Conexión

Connector: 1 x M12; Contacts: gold-plated

Número de entradas/salidas

Number of analogue outputs: 1

Consumo actual

< 10 mA

Suministro de voltaje

24 V

Mostrar

switching status: 4 x 90° LED, yellow

Grado de protección

IP 67

Peso

32.5 g

Dimensiones

M12 x 1 / L = 80 mm
