DI506A ifm ⍾ DIA3010-ZPKG/US/3D/5S

Compact evaluation unit for speed monitoring; Nominal voltage DC [V] : 10...36; Protection class : III; Reverse polarity protection : yes; Total number of outputs : 1; Electrical design : PNP; Output function : normally open; Max. voltage drop switching output DC [V] : 2.5; Permanent current rating of switching output DC [mA] : 250; Short-time current rating of switching output [mA] : 250; Switching frequency DC [Hz] : 100; Short-circuit proof : yes; Overload protection : yes; Sensing range [mm] : 10; (without impact protection housing: flush mountable; with impact protection housing: non-flush mountable 7 mm); Sensing range adjustable : no; Real sensing range Sr [mm] : 10 ± 10 %; (without impact protection housing flush mountable); Operating distance [mm] : 0...5; (with impact protection housing non-flush mountable); Setting range [Imp/min] : 5...300; Correction factor : steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3; Hysteresis [% of Sr] : 10; Start-up delay [s] : 5; (typical); Max. damping frequency [Imp/min] : 15000; Adjustment of the switch point : multiturn potentiometer; Ambient temperature [°C] : -20...50; Mounting : flush mountable; Thread designation : M30 x 1.5; Materials : brass special coating; PBT; PPE; TPE-U; PA 6.6; Items supplied : lock nuts: 2 | Impact protection housing | Mounting clamp

Tipo

Detectores de velocidad

Conexión

Connector: 1 x M12

Número de entradas/salidas

Number of analogue outputs: 1; Number of relay outputs: 2

Consumo actual

< 15 mA

Suministro de voltaje

20...30; (via flat cable) V

Mostrar

switching status: 1 x LED, green | input signal: 1 x LED, yellow

Grado de protección

IP 67

Peso

302 g

Dimensiones

M30 x 1.5 / L = 82 mm
