TM18RP6R BANNER ⍾ 42010

TM18 Series Heavy-Duty Metal Right Angle Sensors; EZ BEAM TM18: Receiver Range: 20m; Input:10-30V dc Outputs: PNP Dark Operate 2 m (6.5 ft.) Cable; Cable Length (m) : 2; Sensing Mode (General) : Opposed; Sensing Mode (Detailed) : Receiver; Housing Style : Barrel; Primary Housing Material : Zinc Die-Cast with Nickel-Plating; Input/Output : Discrete; Max Sensing Distance (mm) : 20000; Quick Disconnect Type : No QD; Operation : Dark Operate; Min Op. Temp. (°C) : -40; Max Op. Temp. (°C) : 70; Output response time (ms) : 1.5 ON/0.75 OFF; Repeatability (µs) : 190; Number of Pins : 3; NEMA Rating : NEMA 6; Max Op. Relative Humidity [%] : 90% @ 50°C; Barrel Diameter (mm) : 18; Opposed Mode Emitter/Receiver : Receiver; Feature: Washdown Rated : Yes; Feature: Encapsulated : Yes

Tipo

TM18

Material de la lente

Polycarbonate

Haz sensor

Visible Red LED

Conexión

Cable

Tiempo de respuesta típico

100 ms

Tipo de fuente de alimentación

DC

Fuente de alimentación

10-30 V dc

Indicador

LEDs

Grado de protección

IP67
