QS18VP6FF50Q BANNER ⍾ 71877

QS18 Series All Purpose Photoelectric Sensor; WORLD-BEAM QS18 Series: Fixed-Field Range: 50 mm; Input: 10-30V dc Output: Complementary Solid State PNP6 in Pigtail Pico-Style Quick Disconnect Connector; Sensing Mode (General) : Proximity; Sensing Mode (Detailed) : Background Suppression (Fixed); Housing Style : Rectangular w/M18 Mount; Primary Housing Material : ABS; Small Visible Spot : LED; Input/Output : Discrete; Max Sensing Distance (mm) : 50; Outputs : PNP; Quick Disconnect Type : M8 (Pico); Min Op. Temp. (°C) : -20; Operation : Light/Dark Operate; Max Op. Temp. (°C) : 70; Output response time (ms) : 0.85; Sensing Beam Wavelength : 630; Repeatability (µs) : 160; Number of Pins : 4; NEMA Rating : NEMA 6; Max Op. Relative Humidity [%] : 95% @ 50°C; Barrel Diameter (mm) : 18; Feature: Quick Disconnect : Yes

Tipo

QS18

Material de la lente

Acrylic

Haz sensor

Visible Red LED

Conexión

Pigtail QD

Tiempo de respuesta típico

100 ms

Tipo de fuente de alimentación

DC

Fuente de alimentación

10-30 V dc

Indicador

LEDs

Grado de protección

IP67
