QS18EP6WQPMA BANNER ⍾ 80849

QS18 Series All Purpose Photoelectric Sensor; WORLD-BEAM QS18 Expert; Divergent Diffuse Range: 300 mm; Input: 10-30V dc Output: PNP150mm Pigtail Euro Quick-Disconnect Connector; Sensing Mode (General) : Proximity; Sensing Mode (Detailed) : Divergent; Housing Style : Rectangular; Primary Housing Material : ABS; Input/Output : Discrete; Max Sensing Distance (mm) : 300; Outputs : PNP; Quick Disconnect Type : M12 (Euro); Operation : Light/Dark Operate; Min Op. Temp. (°C) : -20; Max Op. Temp. (°C) : 70; Output response time (ms) : 0.6; Special Feature: Remote Teach : Yes; Repeatability (µs) : 75; Number of Pins : 4; NEMA Rating : NEMA 6; Max Op. Relative Humidity [%] : 95% @ 50°C; Adjustments : Teach Button; Feature: Timing (Hold/Delay) : Yes; Feature: Quick Disconnect : Yes

Tipo

QS18

Material de la lente

PMMA

Haz sensor

Infrared LED

Conexión

Pigtail PUR QD

Tiempo de respuesta típico

100 ms

Tipo de fuente de alimentación

DC

Fuente de alimentación

10-30 V dc

Indicador

LEDs

Grado de protección

IP67
