M18SP6LP BANNER ⍾ 48658

M18 Series 18mm Metal Barrel-Mount Sensor; EZ-BEAM M18 Series: Polarized Retro Range: 2 m; Input: 10-30V dc Output: Complementary PNP2 m (6.5 ft) cable; Cable Length (m) : 2; Sensing Mode (General) : Retroreflective; Sensing Mode (Detailed) : Polarized; Housing Style : Barrel; Primary Housing Material : Stainless Steel; Input/Output : Discrete; Max Sensing Distance (mm) : 2000; Outputs : PNP; Quick Disconnect Type : No QD; Operation : Light/Dark Operate; Min Op. Temp. (°C) : -40; Max Op. Temp. (°C) : 70; Output response time (ms) : 3; Repeatability (µs) : 750; Number of Pins : 4; NEMA Rating : NEMA 6P; Max Op. Relative Humidity [%] : 90% @ 50°C; Barrel Diameter (mm) : 18; Feature: Washdown Rated : Yes; Feature: Encapsulated : Yes; Feature: Chemical Resistant : Yes; Feature: Health/ Marginal Signal Output : Yes

Tipo

M18

Material de la lente

Acrylic

Haz sensor

Visible Red LED

Conexión

Cable

Tiempo de respuesta típico

100 ms

Tipo de fuente de alimentación

DC

Fuente de alimentación

10-30 V dc

Indicador

LEDs

Grado de protección

IP69
