M18SP6FF100Q BANNER ⍾ 48675

M18 Series 18mm Metal Barrel-Mount Sensor; EZ-BEAM M18 Series: Fixed Field Range: 100 mm; Input: 10-30 V dc Output: Complementary PNPEuro M12 4-pin Integral QD; Sensing Mode (General) : Proximity; Sensing Mode (Detailed) : Background Suppression (Fixed); Housing Style : Barrel; Primary Housing Material : Stainless Steel; Input/Output : Discrete; Max Sensing Distance (mm) : 100; Outputs : PNP; Quick Disconnect Type : M12 (Euro); Operation : Light/Dark Operate; Min Op. Temp. (°C) : -40; Max Op. Temp. (°C) : 70; Output response time (ms) : 3; Repeatability (µs) : 750; Number of Pins : 4; NEMA Rating : NEMA 6P; Max Op. Relative Humidity [%] : 90% @ 50°C; Barrel Diameter (mm) : 18; Feature: Washdown Rated : Yes; Feature: Encapsulated : Yes; Feature: Chemical Resistant : Yes; Feature: Quick Disconnect : Yes; Feature: Health/ Marginal Signal Output : Yes

Tipo

M18

Material de la lente

Acrylic

Haz sensor

Infrared LED

Conexión

Integral QD

Tiempo de respuesta típico

100 ms

Tipo de fuente de alimentación

DC

Fuente de alimentación

10-30 V dc

Indicador

LEDs

Grado de protección

IP69
