M186EQP BANNER ⍾ 02964

M18 Series 18mm Metal Barrel-Mount Sensor; M186EQP 6IN 4 PIN EURO PIGTAIL; Cable Length (m) : 0.15; Sensing Mode (General) : Opposed; Sensing Mode (Detailed) : Emitter; Housing Style : Barrel; Primary Housing Material : Stainless Steel; Max Sensing Distance (mm) : 20000; Quick Disconnect Type : M12 (Euro); Min Op. Temp. (°C) : -40; Max Op. Temp. (°C) : 70; Repeatability (µs) : 375; Number of Pins : 4; NEMA Rating : NEMA 6P; Max Op. Relative Humidity [%] : 90% @ 50°C; Barrel Diameter (mm) : 18; Opposed Mode Emitter/Receiver : Emitter; Feature: Washdown Rated : Yes; Feature: Encapsulated : Yes; Feature: Chemical Resistant : Yes; Feature: Quick Disconnect : Yes; Feature: Health/ Marginal Signal Output : Yes

Tipo

M18

Material de la lente

Polycarbonate

Haz sensor

Infrared LED

Conexión

Pigtail QD

Tiempo de respuesta típico

100 ms

Tipo de fuente de alimentación

DC

Fuente de alimentación

10-30 V dc

Indicador

LEDs

Grado de protección

IP69
