060-217766 Danfoss ⍾ 060217766

Type Code: KP36; Weight: 0.337 Kg; : 80 °C/176 °F for max 120 min; Ambient temp.: -40 - 65 °C; Ambient temp.: -40 - 149 °F; Approval: c UL us UL353, CS C22.2, c UL us UL873, CS C22.2, CCC, CE, EAC, FM, LVD, PZH, RINA, RMRS, RoHS China; Contact function: SPDT; Contact rating: 120Vac,16FLA,96LRA,3APilotDuty; Contact rating: 16 A resistive, single phase; Contact rating: 240 V ac, 8 FLA, 48 LRA; Contact rating: 240V dc,12W pilot duty(0.05 A); Contact rating: 8 A resistive, single phase; Diff.: 0,70 - 4,00 bar; Diff.: 10,00 - 58,00 psi; EAN no.: 5702428432146; Electr. conn. Male/Female: Female; Electr. conn.: Swivel cable connector; Electr. conn. size: NPSM 1/2 - 14; : Insulation: 400V; : Pollution degree: 3; : Rated impulse voltage: 4 kV; : Short circuit prot, fuse: 16A; : Flex, ferrules: 0.5-1.5 mm2; : Flex, no ferrules: 0.7-2.5 mm2; : Solid/stranded: 0.75-2.5 mm2; Enclosure rating: IP30; Nema rating (~): 1; Max. test pressure: 22,0 bar; Max. test pressure: 319,0 psig; Max. Working Pressure: 17,0 bar; Max. Working Pressure: 245 psig; Pack format: Multi pack; Pressure conn. std.: ANSI/ASME B1.20.1; Pressure conn. type: NPT - 1/4-18 Female; Pressure sensing elem.: Bellows; : Switches accessories; Prod. description: Pressure switch; Prod. group: Switches and thermostats; Prod. name: Pressure switch; Pack qty.: 36 PC; Regul. range: 2,00 - 14,00 bar; Regul. range: 29,00 - 203,00 psig; Reset: AUTO; : No; UL approval file name: E31024; UL approval file name: MH27572.

Tipo

KP, Presostatos para la industria ligera
