SM312FP BANNER ⍾ 25916

Lichtleiter-Verstärker: Bauform MINI-BEAM; MINI-BEAM: Plastic Fiber Optic Range: depends on fiber; Input: 10-30 V dc Output: Bipolar: 1 NPN; 1 PNP 2 m (6.5 ft) Cable; Power : DC; Housing Style : Rectangular; Primary Housing Material : Thermoplastic; Input/Output : Discrete; Color LED - Amplifiers : Red; Fiber Type : Plastic and Glass; Output : Bipolar (NPN & PNP); Quick Disconnect Type : No QD; Output Type (Specific) : Single Discrete; Repeatability (µs) : 300; Number of Pins : 4; IP Rating : IP67; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12; Max Op. Temperature (°C) : 70; Min Op. Temperature (°C) : -20; Max Op. Relative Humidity (%) : 90% @ 50°C; Adjustments : Potentiometer; Delay at Power-up (ms) : 100; Indicator Display Type : Indicator LEDs; Housing Material : Thermoplastic

Typ

MINI-BEAM

Connection

Cable

Typische Reaktionszeit

100 ms

Stromversorgung

10-30 V dc

Stromversorgungstyp

DC

Schutzart

IP67
