SM2A31RPDQDP BANNER ⍾ 29565

Industriestandard-Sensor der Bauform Mini-Beam; MINI-BEAM: Clear Plastic Detection Receiver Range: 0 - 0.3 m; Input: 24-240 V ac Output: SPST Solid-state 2-wire Micro 3-pin Integral QD; Sensing Beam : Visible Red LED; Power : AC; Sensing Mode (General) : Opposed; Housing Style : Rectangular w/M18 Mount; Primary Housing Material : Thermoplastic; Input/Output : Solid-State AC Switch; Max Sensing Distance (mm) : 300; Outputs : Solid-State AC Switch; Connection : Pigtail QD; Quick Disconnect Type : 1/2 in. (Micro); Operation : Light/Dark Operate; Min Op. Temp. (°C) : -20; Max Op. Temp. (°C) : 70; Output response time (ms) : 2 ON/1 OFF; Sensing Beam Wavelength : 650; Delay at Power-up (ms) : 300; Repeatability (µs) : 300; NEMA Rating : NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, 13; IP Rating : IP67; Max Op. Relative Humidity [%] : 90% @ 50°C; Lens Material : Acrylic; Adjustments : Potentiometer; Barrel Diameter (mm) : 18; Indicator : LEDs; Feature: Clear Object Detection : Yes; Feature: Encapsulated : Yes; Feature: Quick Disconnect : Yes

Typ

MINI-BEAM

Linsenmaterial

Acrylic

Sensorstrahl

Visible Red LED

Connection

Pigtail QD

Typische Reaktionszeit

300 ms

Stromversorgungstyp

AC

Stromversorgung

24-240 V ac

Indikator

LEDs

Schutzart

IP67
